Overview
N722AP USB dongle adapter, base on TI‘s CC2652R and CC2592, up to +22dBm output, ideal for IoT gateways, range extension, and development. It supports 2.4 GHz protocols including Zigbee 3.x, Bluetooth 5.2 LE, Thread, and 6LoWPAN.‍

Key Features

High-Power RF Performance: +22 dBm maximum transmit power and -100 dBm receiver sensitivity .
Multi-Protocol Support: Zigbee 3.0/3.2, Bluetooth® 5.0/5.2 LE, Thread, 6LoWPAN, and IEEE 802.15.4 networks.
Ready-to-Use USB Interface: CDC device, supports Windows, Linux (including Raspberry Pi), and Android hosts.
Integrated User Interface: Onboard multi-color status LED and a programmable tactile button.
Complete Development Platform: All CC2652R debug pins (JTAG/SWD) are accessible.
Compact & Integrated Design: The single PCB houses the MCU, PA/LNA, USB bridge, PCB antenna (with IPEX connector option).

Target Applications

Smart Home/Commercial Gateways: As a high-power coordinator for Zigbee or Thread mesh networks.
Wireless Router/Repeater: Extends the range of existing 2.4 GHz IoT networks.
IoT Prototyping & Development: Primary tool for developing and testing applications for the CC2652R platform.
Network Sniffing & Diagnostics: Capturing and analyzing 2.4 GHz protocol traffic.
PC-Connected Sensor Hub: Aggregating data from multiple wireless sensors to a central computer.

Technical Specifications

Parameter	Specification
Core ICs	TI CC2652R + CC2592 (PA/LNA)
Frequency Band	2400 – 2480 MHz (2.4 GHz ISM)
Supported Protocols	Zigbee 3.x, Bluetooth 5.0/5.2 LE, Thread, 6LoWPAN, IEEE 802.15.4, Proprietary
Max. Output Power	+22 dBm (Programmable)
Receiver Sensitivity	-100 dBm (typical)
Max. Data Rate	2000 kbps
Typical Range	> 500 m (Line-of-sight, 250 kbps)
Host Interface	USB 2.0 (Virtual COM Port)
User Interface	1x RGB Status LED, 1x Programmable Button
Antenna	Integrated PCB Antenna + IPEX Connector (for external antenna)
Power Supply	5V USB Bus Power
Current Consumption	TX: ~160 mA (@ +22 dBm), RX: 15 mA
Operating Temperature	-30°C to +75°C
Dimensions (PCB)	37 x 17 x 7 mm
Compatible OS	Windows 7/10/11, Linux, Android

Development Support

Software Development Kit (SDK): Fully compatible with TI's SimpleLink™ CC13xx/CC26xx SDK.
Programming: Supports firmware updates via the USB serial bootloader or direct JTAG/SWD debugging.
Hardware Documentation: Reference schematics are available to support custom modifications and integration.

Ordering Information

Model	Core ICs	Protocol Focus	Output Power	Frequency
N722AP	CC2652R + CC2592	Zigbee, BLE, Thread, 6LoWPAN	+22 dBm	2400-2480 MHz

Simplified Selection Guide for N72-Series USB Adapters

Model	Best For...	Because it offers...
N725AP	Fastest & Easiest Start	Pre-built, certified software for Zigbee, BLE, and Thread.
N726AP	Latest Features & Top Performance	Bluetooth 5.3, large memory (1MB), and advanced security.
N722AP	Full Custom Control	352k flash, A powerful, flexible platform to build or heavily customize your own wireless stack.
N710BP	Proven & Cost-Effective Zigbee/Thread	512K flash, A stable, reliable, and affordable solution for zigbee networks.
