Overview
The N725AP adapter is an advanced, high-performance USB wireless dongle designed to serve as the core of modern, high-coverage IoT networks. It combines the cutting-edge Texas Instruments CC2652R7 multi-protocol wireless microcontroller with the CC2592 2.4 GHz RF front end, delivering a powerful +22 dBm output to overcome range limitations and ensure robust connectivity. Engineered to support the latest IoT standards—including Matter, Thread, Zigbee, and Bluetooth® 5.2 Low Energy—this compact device is the ultimate tool for building future-proof smart home hubs, commercial gateways, and professional development platforms.

N725AP USB Dongle datasheet‍ ‍C‍C2652R7 DATASHEET ‍

Key Features

High-Power RF for Maximum Range: +22 dBm transmit power and excellent sensitivity ensure reliable communication over extended distances, ideal for large-scale deployments.
Future-Proof Multi-Protocol Support: Natively supports Matter, Thread, Zigbee 3.x, Bluetooth 5.2 LE, 6LoWPAN, and IEEE 802.15.4. The CC2652R7's Dynamic Multiprotocol Manager (DMM) enables concurrent operation of different wireless standards.
Powerful Processing Core: Features an ARM® Cortex®-M4F main processor and an ultra-low-power sensor controller, providing ample resources for complex gateway logic and edge processing.
Plug-and-Play USB Simplicity: Enumerates as a standard serial (CDC) device, compatible with Windows, Linux (including Raspberry Pi), requiring no custom drivers for immediate use.
Integrated Development Interface: Includes a user-programmable button, a multi-color status LED, and accessible debug pins (JTAG/SWD) for full firmware control, development, and field updates.
Compact, All-in-One Design: Integrates MCU, PA/LNA, USB bridge, PCB antenna (with IPEX connector option), and user interface on a single, rugged PCB within a standard USB form factor.

Target Applications

Universal Smart Home Hubs: The ideal hardware foundation for Matter/Thread/Zigbee bridges and controllers.
Commercial & Industrial IoT Gateways: High-power coordinator for building automation, retail, and asset tracking networks.
Wireless Network Extender/Router: Boosts the range and reliability of existing 2.4 GHz mesh networks.
Advanced Protocol Development & Testing: Primary platform for developing and validating applications for Matter, Thread, and other emerging standards.
PC-Connected Network Analyzer: For sniffing, diagnosing, and managing complex wireless IoT ecosystems.

Technical Specifications

Parameter	Specification
Core ICs	TI CC2652R7 + CC2592 (PA/LNA)
Frequency Band	2360 – 2500 MHz (2.4 GHz ISM)
Supported Protocols	Matter, Thread, Zigbee, Bluetooth 5.2 LE, IEEE 802.15.4, 6LoWPAN, Proprietary
Max. Output Power	+22 dBm
Receiver Sensitivity	Excellent (Typical -100 dBm range)
Max. Data Rate	2000 kbps
Typical Range	> 400 m (Line-of-sight)
Host Interface	USB 2.0 (Virtual COM Port)
User Interface	1x Programmable Button, 1x Status LED
Antenna	Integrated PCB Antenna + IPEX Connector (for external antenna)
Power Supply	5V via USB Bus Power
Current Consumption	RX: ~35 mA
Operating Temperature	-30°C to +75°C
Dimensions (PCB)	37 x 17 x 7 mm
Compatible OS	Windows, Linux, Raspberry Pi OS

Development Support

Software Development Kit (SDK): Fully compatible with TI's SimpleLink™ CC13xx/CC26xx SDK, including DMM examples for multiprotocol operation.
Programming & Debugging: Supports firmware updates via USB bootloader and in-circuit debugging via exposed JTAG/SWD pins.
Reference Documentation: Hardware design guides and application notes available to accelerate integration.

Ordering Information

Model	Core ICs	Key Protocols	Output Power	Frequency
N725AP	CC2652R7 + CC2592	Matter, Thread, Zigbee, BLE 5.2	+22 dBm	2360-2500 MHz

Why Choose the N725AP?

Build for the Future: Hardware-ready for Matter and Thread, ensuring your product remains relevant.
Solve Coverage Challenges: High-power RF design eliminates weak spots in wireless networks.
Simplify Development: A single, versatile platform replaces multiple protocol-specific tools.
Professional Grade: Robust design supports 24/7 operation in demanding environments.

Empower Your 2.4 GHz Network with High-Performance Connectivity.

Feature / Model	22dBm N722AP Dongle	22dBm N725AP Dongle	22dBm N726AP Dongle	22dBm N710BP Dongle
Core MCU	CC2652R + CC2592	CC2652R7 + CC2592	CC2674R10	CC2538 + CC2592
On-Chip Flash	352 KB	704 KB	1 MB	512 KB
Frequency	2400 MHz	2400 MHz	2400 MHz	2400 MHz
Core Value	High-Performance Custom Stack	Pre-Integrated & Certified Stacks	High-Performance Custom Stack	Pre-Integrated & Certified Stacks
Development Focus	Develop highly optimized, proprietary stacks.	Develop your application only, using pre-built, certified stacks.	Develop highly optimized, proprietary stacks.	Develop your application only, using pre-built, certified stacks.
Ideal For	Developers needing full RF control for custom or optimized Zigbee/Thread/BLE networks.	Projects requiring fast time-to-market with certified Zigbee, BLE, Thread, or Matter stacks.	Next-gen applications needing Bluetooth 5.3, large memory, and a platform for custom protocols.	Cost-sensitive projects based on mature Zigbee or Thread networks, prioritizing proven stability.
Next Step		[Learn More →]	[Learn More →]	[Learn More →]

Simple Selection Guide:

Choose the N72XAP Series (N722AP /N725AP /N726AP/N710BP ) if you are building a unique, proprietary protocol and have the resources for full-stack development.
Choose the N710BP if your project is based on mature Zigbee or Thread and you prioritize a proven, integrated solution to accelerate time-to-market.
