N732AP CC2652R ZigBee/BLE dongle designed for 2.4G band, ZigBee/BLE router or gateway uesd. ZigBee/BLE dongle up to +5 dBm output power and down to -100dBm sensitivity.
N732AP ZigBee dongle USB intergrate CC2652R two color LED, PCB antenna, USB to UART chip and tact switch. Dongle application ZigBee gateway, router, etc.
N732AP Dongle Description
The N732AP dongle based CC2652R. CC2652R is a multiprotocol 2.4 GHz wireless microcontroller (MCU) supporting Thread, Zigbee®, Bluetooth® 5.2 Low Energy, IEEE 802.15.4, IPv6-enabled smart objects (6LoWPAN), proprietary systems, including the TI 15.4-Stack(2.4 GHz), and concurrent multiprotocol through a Dynamic Multiprotocol
Manager (DMM) driver. The device is optimized for low-power wireless communication and advanced sensing in building security systems, HVAC, medical, wired networking, portable electronics, home theater & entertainment, and connected peripherals markets.
N732AP dongle radio sensitivity and robustness (selectivity and blocking) performance for Bluetooth ® Low Energy (-105 dBm for 125 kbps LE Coded PHY),
