Up to 25dBm output power, and down to -126dBm sensitivity. 169M, 433M, 868M, 915M used. CC1311R3 support AT command and UART.
N532DS integrated TI CC1311R3 and PA chip, which is suitable for 433M, 868MHz and 915MHz band. CC1311 module has the characteristics of low cost, low power consumption and small size. The module is designed with 4-layer board, with excellent impedance matching and anti-interference. The module is mainly for Internet of things, intelligent home, wireless meter reading, scientific research and medical treatment, and medium and long-distance wireless communication equipment. CC1311 module leads all pins out for secondary development.
N532DS (CC1311R3) is suitable for free frequency band in EU.
RF Interface
Parameter
Introduce
Frequency
169M, 433M, 860M, 915MHz
Support ISM
Output Power
+25dBm
The maximum power 300mW(vcc= 3V, vccpa = 5V)
Sensitivity
-110dBm
50kbps
Symbol Rate
0.3-4000kbps
Software programming control
Deviation
+/-10kHz
Antenna interface
Distance
4000m
In clear and open environment, the antenna gain
is 3 dBi, the height above the ground is 2.5 meters,
